Yakima CopperHead Mode D'emploi

WHEEL STRAP (1X)
END CAP (1X)
LOCKING SKEWER (1X)
IMPORTANT WARNING
IT IS CRITICAL THAT ALL YAKIMA RACKS AND ACCESSORIES BE PROPERLY AND SECURELY ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD RESULT IN AN AUTOMOBILE
ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH TO YOU OR TO OTHERS. YOU ARE RESPONSIBLE FOR SECURING THE RACKS AND ACCESSORIES TO YOUR CAR,
CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR, AND DAMAGE. THEREFORE, YOU MUST READ AND
UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS SUPPLIED WITH YOUR YAKIMA PRODUCT PRIOR TO INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS
AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A
PROFESSIONAL INSTALLER.
1033568C - 1/18
CARRIAGE BOLT (1X)
SNAP AROUND (1X)
HEX KEY (1X)
WRENCH (1X)
Type of
Rack
COVER (1X)
POD
SCREWS
(3X)
*CROSSBAR SPREAD
Your crossbar spread is
the distance between
Min. - Max.
Crossbar
Spread*
Load
1 or more 16" - 42"
bikes 41cm - 107cm
DO NOT EXCEED RACK WEIGHT LIMITS!
the crossbars.
DESIGNED FOR FORKS
WITH SAFETY TABS.
Forks with
Safety Tabs
Part #1033568 Rev.C
Limits
35 lbs./bike
16kg/bike
