GE RAB24 Instructions D'installation page 4

material.
Caulk*
Room
cabinet
Caulk*
*NOTE: It is critical to caulk around the perimeter of the wall
sleeve on all four sides and on the outside and the roomside
For installation in extra thick walls
1. The wall sleeve should not be installed in a thick wall where
2. If the wall sleeve is being installed in a wall where the recess
Wall
Case
Sleeve
*NOTE: It is critical to caulk around perimeter of wall sleeve
on all four sides where it joins the building to prevent air and
Installation Instructions
Steel lintel
Caulk*
Wall
Case
Sleeve
Outdoor
grille
Caulk*
Outdoor
grille
Flashing
Caulk*
Drip rail
A Quality Product of GE Appliances
Electrical Requirements (230V/208V)
Provisions should be made to have the proper electrical outlet
near the wall sleeve. All wiring should be made in accordance
a wall receptacle located within the area shown in the table
below.
A
Inside
Wall Receptacles
120V/115V 15 amp 230V/208V 20 amp
"tandem" type
All wiring should be made in accordance with local electrical
codes and regulations.
See the Owner's Manual for how to connect electrical supply.
NOTE: Aluminum wiring in structure may pose special
Drain Kit (optional)
If it is necessary to install a drain kit on this wall sleeve,
the following kit is available:
RAD10 External Drain
from the unit and the building.
To install, follow the instruction manual included with
the kit.
4
B
MODEL "A" "B"
115V 50" 74"
230/208V
39" 65"
"perpendicular" type
