No-Drill MudFlaps
1
Thoroughly wash your vehicle, removing all
dirt, debris and stains from each fender in the
areas where the MudFlaps will be installed.
2
Park the vehicle on level ground with the
wheels turned fully to the left. Begin with the
driver's side MudFlap installation.
3
3
Locate the (3) three factory Phillips head screws at
the inner fender as indicated.
5
5
Using the MudFlap marked "LH," place it up to the
fender and align with the corresponding holes.
Installation Instructions
4
4
Using a ratchet, appropriate socket and supplied
Phillips bit, remove the (3) three factory Phillips head
screws. They will be reused.
6
6
Take the (3) three previously removed factory
Phillips head screws and install through the holes
in the MudFlap with the ratchet, appropriate socket
and supplied Phillips bit and tighten to a snug fit.
What You Need
Ratchet and Socket Set*
Flat Screwdriver*
*Not included
48MF568 Parts Kit:
(2) U-Clips
48MF569 Parts Kit:
(1) Phillips bit
