4. Mounting schoolbag hook and lattice
bookshelf
Uno-M-Step 22405-22413
UnoBean-Step 01468
Turn the table top over and lay on a clean assembly surface
(e.g. protective cover, etc.).
-
Schoolbag hook
Models 22405 to 22413 and 01468
Fasten the schoolbag hook
screws in the designated holes in the frame. On model
01468 (one-seater) the schoolbag hook is normally
mounted on the left side from the user side
12
All manuals and user guides at all-guides.com
(2)
(2)
(4)
(3)
with two 4.8x19 mm
(1)
(4)
.
(1)
(1)
-
Lattice bookshelf
LIGNOdur 22405, 22408, 22409, 22411
Position the lattice bookshelf
holes (distance
(3)
from the user side
68 mm for model 22411). Screw on each lattice books-
helf with four 4.8x13 mm sheet screws.
-
Lattice bookshelf
LIGNOpal 22406, 22407, 22410, 22412, 22413,
01468
Position the lattice bookshelf
holes (distance
from the user side
(3)
133 mm for model 01468). Screw on each lattice
bookshelf with four 5x20 mm sheet screws.
(2)
(4)
(2)
(3)
(4)
over the predrilled
(2)
(4)
is 88 mm or
over the predrilled
(2)
is 88 mm or
(4)
