battery can fall out and even injure a child if the vehicle tips over. Risk of fire.
Do not bypass.
• If a battery leaks, avoid it from contacting with the leaking acid and put the
damaged battery into a plastic bag. Refer to the information in "Disposal of
Battery" for proper disposal.
• If acid comes in contact with the skin or eyes, rinse with cool water for at least
15 minutes and call for a doctor.
• If mistakenly take a large amount of acid, take a large amount of water, milk of
magnesia or egg-white immediately. Call a physician.
Specification Instruction
Name
Battery
Motor
Applicable age
Maximum load
Charge time
Charger
Speed
※Above parameters are selected for customers, the specific parameters are
based on the actual parameters.
WARNING: The toy is to be assembled by an adult.
In an unassembled state, it contains potentially hazardous sharp points, sharp
edges and small parts, so please keep out of the baby's reach.
WARNING: To reduce the risk of injury, adult supervision is required.
Never use in roadways, near motor vehicles, on or near steep inclines or steps,
swimming pools or other bodies of water, always wear shoes, and never allow
more than 1 rider.
06
Specification
12V 4.5AH*1
12V*2
3-7 years old
66 LBS (30 KG)
Charge 8-12 hours
12V 500mA
1.2-2.5MPH (2-4 km/h)
Product Exploded View
Accessories List
No.
Name
4*12mm flat head
1
screws
4*16mm flat head
2
screws
4*12mm round head
3
screws
4*10mm round head
4
screws (Black)
5
M10 Washer
6
M5*30 machine screws
Quantity
Use
Installation of digging bucket
4
(part B) x2
Installation of seat (part H) x2
Installation of front windscreen
2
frame (part E) x2
Installation of driven connector
6
(part N) x6
Installation of gear switch
4
(part P) x4
Installation of front wheel x4
6
Installation of rear wheel x2
Installation of bucket arm
6
(part C) x6
07
