12
Adjusting the traverse
• Adjusting the way the carriage slides on the
rail (SEE FIGS. 7a & 7b).
- This operation requires a No. 4 Allen key and a
flat No. 13 spanner.
- Adjustment is made in the horizontal plane by
tightening eccentric screws H and in the vertical
plane by tightening eccentric screws I
- To adjust the eccentric screws: place the Allen
key in the screw's hexagonal hole and use the
flat spanner to loosen the tightening nut J
slightly. Tighten the eccentric screw with the
Allen key until the bearing is adjusted correctly.
Retighten the nut and check that the carriage
slides correctly.
Retighten the two eccentric screws in
the same plane at the same time.
To set the vertical plane, pass the
Allen key on the one hand through the
height-adjustment plate (24) and on
the other through the hole behind the
switch.
13
Important advice
• Tighten all the nuts and bolts regularly.
• When storing the machine, we recommend
removing the blade and storing it carefully.
• Check that there is sufficient water supply during
operation.
• Tighten the blade firmly.
• Make sure the contact faces of the flanges, blade
and axle are clean.
The
manufacturer
responsibility for loss or damage
resulting
modification, alteration or powering
that does not conform to the
manufacturer's original specifications.
The noise level of this machine is
measured according to the S 31.069
standard.
At the work station, the sound
pressure level may exceed 85 db (A)
In this case individual protection
measures must be taken.
28
declines
from
misuse
or
14
Repairs
Contact your supplier who is entirely at
S
your service to carry out repairs in the
A
shortest time at the best possible price.
V
15
Spare parts
For rapid delivery of spares and in order to avoid
any wasted time, it is necessary to remind your
supplier of the details shown on the instruction
plate on the machine with each order, as well as
the reference of the part to be replaced.
Item number
16
Scrapping
In the event of deterioration and
scrapping of the machine, the
following items must be disposed of
in accordance with the requirements
of the legislation in force.
• Main materials :
- Motor : Aluminium (AL), Steel (AC),
Motor :
Copper (CU), Polyamide (PA)
- Machine : Steel sheet (AC), Cast iron (FT)
all
any
The instructions for use and spare parts found in this
document are for information only and are not binding.
As part of our product quality improvement policy, we
reserve the right to make any and all technical
modifications without prior notice.
00000000
(0)
Quantity
See exploded view
