EN
3

INSTALLATION

3.1

Mounting the receiver

> > > Illustration 4
CAUTION
Ensure the mains power supply is at the correct distance.
1] Secure the bracket to the wall.
2] Secure the housing to the bracket.
3.2

Wiring the motor

> > > Illustration 5
DANGER
Risk of electrocution
The receiver must not be connected to the mains power supply during connection to the motor.
The motor cable must be placed in the receiver's 230 V insulation area.
1] Connect the motor to the receiver in accordance with the wiring shown below:
Receiver terminal
4
5
6
7
NOTICE
The motor's direction of rotation shall then be checked and reversed if necessary.
3.3

Anti-fallback wiring

> > > Illustration 6
DANGER
The anti-fallback device must be wired.
3.4

Power supply wiring

> > > Illustration 7
1] Connect the neutral (N) to terminal 1 of the receiver.
2] Connect the live (L) to terminal 2 of the receiver.
3] Connect the earth wire to terminal 3 of the receiver.
4] Lock the power supply cable with the cable clamp provided.
32
Motor wire
Yellow/green
Black
Blue
Brown
©
