3G/4G Modem
SIM card
SIM card
Copper Ethernet
Threaded, circular, RJ-45
Port
Threaded, circular, 2
Direct DC Power
contact DC power
Input Port
Chassis Protective Earth
Earth Ground
Ground terminal
1.3 Specifications
The Kona Macro Gateway specifications are listed in Table 3.
Attribute
Dimensions
Weight
Operating Temperature
Relative Humidity
Operating Altitude
Power Input, Direct DC
Power Input, PoE
Power Consumption
Weather Tightness
Regulatory Compliance
Surge Protection
Kona Macro User Guide
TEKTELIC Communications Inc.
Industry standard, located behind SIM card access
port cover
Shenzhen Chogori Technology Co., Ltd. approved
mating connector (p/n 33000111-02 or equivalent)
Shenzhen Chogori Technology Co., Ltd. approved
mating connector (p/n 23002211-02, or equivalent)
Industry standard 2-hole lug, 1/4 x 0.75" spacing
Table 3: Kona Macro Gateway Specifications
Specification
222.2mm (8.7") wide x 101mm (4.0") deep x 287.3mm (11.3") tall
5.1 kg (11.3 lbs)
-40°C to 60°C (-40°F to 140°F) at sea level Including solar loading.
10% to 100%
-60 m to 4,000 m (-197 ft to 13,123 ft)
48 VDC nominal, 37 to 57 VDC operating range.
Positive or negative ground referenced feed. SELV source required.
5A recommended input overcurrent protection (2A minimum to 10A
maximum allowed).
802.3 at (Type 2 Class 4), Mode A or Mode B or 4-pair Mode.
20 W maximum
UL Type 6 (IP-67)
CSA/UL 60950-1 & CSA/UL 60950-22, CE IEC 60950-1
FCC Pt. 15, RSS-247, EN 301 489-1
FCC Pt. 27 (North American 2 Variant Only)
All interfaces are protected to primary levels.
