Mono and Dual Panel Heat Selection
Selector switches located on the control panel provide a choice of Half
Heat or Full Heat output to suit varying conditions and for economy of
operation as follows:
Half Heat Setting - left hand side - This switch as shown in Fig. 2
provides half heat output when activated. When it is activated a neon light 'x'
illuminates above the control button and the left hand side element turns on.
Half Heat Setting - right hand side - This switch as shown in Fig.
2
provides a
half
heat output when activated. When it is activated a neon
light 'x' illuminates above the control button
turns on.
Maximum
Heat Setting
Maximum output is achieved with both left and right hand side switches on
and all neons illuminated.
Note that the product wil only operate with the On/Off button in the 'On'
position and all neons illuminated.
DIGITAL TIMER OPERATION
(Fig. 3)
IMPORTANT: Remember to observe all safety warnings when operating
the heater on auto setting, either attended or unattended.
The timer allows you to select 'AUTO' or 'MAN ON' by pressing the 'MODE'
button until the required MODE appears at the bottom of the timer display.
'AUTO' MODE allows the heater to switch ON and OFF according to a set
24 Hour program period (see 'Setting Programs' section below).
'MAN ON' MODE allows power to the heater uninterrupted by the program
settings.
Key Lock:
If 'ENTER' and 'MODE' are pressed within 1 second, the keys will be
locked. The user will know the keys are locked as the lock symbol ' ' will
be displayed on the top left hand corner of the screen. To unlock the keypad,
press 'ENTER' and then 'MODE' within 1 second.
Initial Operation
For initial use, plug the heater into a regular household power point and
turn the power on. The timer is now ready to be set up for use.
Setting Current Time
1. Hold the 'PROGRAM' button until the clock symbol
screen. The user can now set the clock.
2. The hour digit will flash. To adjust the hour use the '-' & '+' buttons.
Confirm the hour digit by pressing 'ENTER'.
3. Once 'ENTER' has been pressed the minutes will flash. To adjust the
minutes use the '-' & '+' buttons. Confirm the minute digit by pressing
'ENTER'.
4. The timer now returns to the default display.
5. To reset incorrect time, repeat previous steps.
Once the correct time is set, a total of four ON/OFF time programs can be
set for operation.
Setting Programmes
Press the 'PROGRAM' key to set the programs.
You are now setting the programs starting with P1 'ON'.
SETTING P1 ON TIME:
1. To set the hour use the '-' & '+' buttons. Confirm the hour digit by pressing
'ENTER'.
2. To set the minutes use the '-' & '+' buttons. Confirm the minute digit by
pressing 'ENTER'.
Note: The minutes can only be set in 10 minute blocks in programme
'MODE'.
SETTING P1 OFF TIME:
3. To set the hour use the '-' & '+' buttons. Confirm the hour digit by pressing
'ENTER'.
4. To set the minutes use the '-' & '+' buttons. Confirm the minute digit by
pressing 'ENTER'.
Repeat steps 1 to 4 to programme P2, P3 & P4. After programming P4
'OFF' you automatically exit to the default display.
At any time while programming the timer you can press the 'PROGRAM'
button to exit to the default display.
Note: If the 'ON' time is the same as the 'OFF' time the appliance will
ignore the program.
and the right hand side element
appears on the
The Advance Function
When in 'AUTO' MODE, if the '+' button is pressed for longer than 2
seconds the programme will ADVANCE to the next setting programmed
and will only revert back to the program when the subsequent programme
time is reached. When the 'ADVANCE' function is running the 'ADVANCE'
segment will be displayed on the LCD screen. If the '-' button is pressed
when the 'ADVANCE' programme is running the 'ADVANCE' feature will
be automatically cancelled and the programme will run as normal.
Note - Timer Memory Back Up Batteries - Once the heater has been
left plugged in with the socket switched on for at least 72 hours the timer's
memory back up batteries will be fully charged.
Once the timer batteries are fully charged, if there is a power cut or if the
heater is disconnected from the mains for less than six months, then the
timer will continue to keep time & the settings in the memory will remain
intact.
If however the timer back up batteries have not been charged fully, or if the
heater is deprived of power for longer than six months, then the time and
the programme settings are likely to be lost and you may therefore need
to reset the time and the programme before using the AUTO MODE again.
Storage
If the radiator is not required for long periods, for example during the
summer, it should be stored in a dry place and preferably covered to
prevent the accumulation of dirt and dust. The plug and cord can be stored
in the storage area provided – see Fig. 4 The cord should be neatly coiled
around the hooks provided and the plug inserted into the pin-hole in the
central compartment.
Safety Overheat Protection
For your safety this appliance is fitted with a thermal cut-out. In the event
that the product overheats for some reason, the cut-out prevents excessive
temperatures on the product by cutting the power to the heater. Once the
heater has cooled down, it will reset automatically, it will continue to cycle on
and off automatically until the reason for overheating is removed.
Recycling
For electrical products sold within the European Community.
At the end of the electrical products useful life it should not be
disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling
advice in your country.
Cleaning
WARNING - ALWAYS DISCONNECT THE POWER SUPPLY BEFORE
CLEANING THE HEATER.
Do not use detergents, abrasive cleaning powder or polish of any kind on
the body of the heater.
Allow the heater to cool, then wipe with a dry cloth to remove dust and a
damp cloth (not wet) to clean off stains. Be careful not to allow moisture
in to the heater.
After Sales Service
Should you require after sales service or should you need to purchase any
spares, please contact the retailer from whom the appliance was purchased
or contact the service number relevant to your country on the warranty card.
Please do not return a faulty product to us in the first instance as this may
result in loss or damage and delay in providing you with a satisfactory
service.
Please retain your receipt as proof of purchase.
Model Identifier(s):
Heat output
Nominal heat output
Minimum heat output (indicative)
Maximum continuous heat output
Auxiliary electricity Consumption
At nominal heat output
At minimum heat output
In standby mode
Type of heat output/ room temperature control
With mechanical thermostat room temperature control
Contact details
- 2 -
Cadiz M
Pnom
2.0
kW
Pmin
1.0
kW
Pmax,c
2.0
kW
elmax
0.0
kW
elmin
0.0
kW
elSB
0.0
kW
Yes
GLEN DIMPLEX FRANCE
12 Boulevard du Mont d'Est - 7/10 Porte Neuilly
Maille Nord III, Hall A
93160 NOISY-LE-GRAND - France
