Cadiz Eco
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
Model
Description
CADIZ M
Switch, Thermostat & Digital Timer Control
IMPORTANT SAFETY ADVICE
If the appliance is damaged, check immediately
with the supplier before installation and operation.
WARNING: This appliance must not be used in
a bathroom.
WARNING: Do not use in areas where petrol,
paint or flammable liquids are used or stored.
DO NOT put objects through the openings of the
appliance. This could lead to functional faults,
possibly to the ignition of the object.
If the mains lead is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualified person in order to avoid a
hazard.
Unplug the heater when not required for long
periods.
WARNING: Do not use this heater in the
immediate surroundings of a bath, a shower or
a swimming pool.
WARNING: This heater must not be located
immediately below a fixed socket outlet.
The heater carries a warning symbol to
alert the user to the risk of fire that exists
if the heater is accidentally covered.
WARNING: In order to avoid a hazard due to
inadvertent resetting of the thermal cut-out,
this appliance must not be supplied through an
external switching device, such as a timer, or
connected to a circuit that is regularly switched
on and off by the utility.
This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience or knowledge if they have been given
supervision or instruction concerning the use of
the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall
not be made by children without supervision.
Children of less than 3 years should be kept away
unless continuously supervised. Children aged
from 3 years and less than 8 years shall only
switch on/off the appliance provided that it has
been placed or installed in its intended normal
operating position and they have been given
supervision or instruction concerning the use of
the appliance in a safe way and understand the
hazards involved. Children aged from 3 years and
less than 8 years shall not plug in, regulate and
clean the appliance or perform user maintenance.
CAUTION: Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
Watts
vulnerable people are present.
2000
If the mains lead is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualified person in order to avoid a
hazard.
GENERAL NOTES
The heater is designed for operation on an AC electricity supply, and is
suitable for use in domestic dwellings and similar indoor locations.
Always ensure that the appliance is stood on a firm, level base near to, but
not directly beneath, a suitable fixed socket outlet.
The heater is fitted with wheels, castors and a handle for ease of movement.
Selector switches provide a choice of heat output and an adjustable
thermostat enables the room temperature to be controlled accordingly. It
is supplied with a cord and plug ready for use.
The supply cord should be uncoiled before use (see 'Storage').
DO NOT pull the heater along by the mains lead.
Important - The heater must only be operated with the wheels and castors
fitted and in the upright position as shown in Fig. 1.
Warning – The heater complies with stringent safety standards but to ensure
efficient operation surfaces of the heater will become hot and contact with
these areas should be avoided, particularly between the air outlet slots on
the top and sides.
The control panel area is designed to be at a far lower temperature to allow
the safe operation of the controls at any time. Momentary contact with any
part of the heater should not cause injury. However aged, infirm persons or
young children should not be left unsupervised in the vicinity of the heater.
Please Note – After switching the heater on for the first time and after an
extended period of non-use a smell may be noticed, this is quite normal –
the fumes are non-toxic and will quickly disappear. We recommend that you
open a window to ventilate the room when using the heater during this time.
Used in an environment where background noise is very low, it may be
possible to hear a sound which is related to the element. This is normal
and should not be a cause for concern.
Positioning the Heater
Select the position for the heater ensuring there is clearance from any
furniture and fittings of at least 300mm above the heater and 150mm
each side. The appliance should only be operated on a flat stable surface.
Operation
Important: Objects or clothing must not be placed on this heater. Before
using the heater ensure that all warnings and instructions have been read
carefully.
To bring the heater into use plug it in. Neon indicating lights located at the
controls area will glow when the appliance is actually heating.
CONTROLS
Thermostat
The Thermostat (see 'T' in Fig. 2) controls the heat output according to
the room temperature. This ensures that the heater will not produce heat
unnecessarily when the room is warm. To set the temperature you require,
turn the thermostat knob clockwise until the required setting is reached.
Alternatively to heat a cold room quickly, turn the thermostat knob up fully.
When the room has reached the desired temperature, turn the thermostat
knob anti-clockwise until the thermostat just clicks off. The heater will now
automatically operate at this temperature. The thermostat also has a frost
protection setting marked '
garages, to prevent frost damage. If the thermostat is set to its minimum
setting '
', the heater will cycle on and off to maintain a temperature of
approximately 5° to help protect against frost.
Note – Should the heater fail to come on when the thermostat is at a low
setting, this may be due to the room temperature being higher than the
thermostat setting.
On/Off button
This button controls the electricity supply to the elements.
Off button is activated a neon light 'Y' illuminates above the control button.
To turn off press the button 'O' located directly above the On/Off button.
- 1 -
'. This setting is useful in areas such as
When the On/
