Input type
Volt
TC type:
E, J, K, L, N, T, U
TC type: B, R, S,
W3, W5, LR
EMC immunity influence .................................... < ±0.5% of span
Extended EMC immunity:
NAMUR NE 21, A criterion, burst ...................... < ±1% of span
Effect of supply voltage variation ................ < 0.005% of span / VDC
Max. wire size .............................................. 1 x 1.5 mm
Humidity ...................................................... < 95% RH (non-cond.)
Dimensions .................................................. 109 x 23.5 x 104 mm
Protection degree ........................................ IP20
Weight (1 / 2 channels) ................................ 145 / 185 g
Electrical specifications, inputs:
Max. offset................................................... 50% of selec. max. value
TC inputs:
Min.
Type temperature
B +400°C
E -100°C
J -100°C
K -180°C
L -100°C
N -180°C
R -50°C
S -50°C
T -200°C
U -200°C
W3
W5
LR -200°C
18
All manuals and user guides at all-guides.com
Basic values
Basic
accuracy
≤ ±10 µV
≤ ±1°C
≤ ±2°C
Max.
temperature
+1820°C
+1000°C
+1200°C
+1372°C
+900°C
+1300°C
+1760°C
+1760°C
+400°C
+600°C
0°C +2300°C
0°C +2300°C
+800°C
6334V105
Temperature
coefficient
≤ ±1 µV / °C
≤ ±0.05°C / °C
≤ ±0.2°C / °C
2
stranded wire
Min.
span Standard
100°C IEC584
50°C IEC584
50°C IEC584
50°C IEC584
50°C DIN 43710
50°C IEC584
100°C
IEC584
100°C IEC584
50°C
IEC584
50°C DIN 43710
100°C ASTM E988-90
100°C ASTM E988-90
50°C GOST 3044-84
