Operating Guide
AVP, AVP-F – PN 16,25/DN 15 – 50
AVP (PN16)
DN 15 - 32
∆p = 0.05 - 0.5
∆p = 0.2 - 1.0
∆p = 0.8 - 1.6
AVP (PN25)
DN 15 - 25
∆p = 0.2 - 1.0
∆p = 0.3 - 2.0
AVP-F (PN25)
DN 15 - 25
∆p = 0.2
∆p = 0.5
© Danfoss | Climate Solutions | 2025.01
AVP-F (PN16)
DN 15 - 32
∆p = 0.2
∆p = 0.3
∆p = 0.5
DN 32 - 50
∆p = 0.2 - 1.0
∆p = 0.3 - 2.0
DN 32 - 50
∆p = 0.2
∆p = 0.5
AVP (PN25)
DN 15 - 50
∆p = 0.2 - 1.0
∆p = 0.3 - 2.0
DN 15 - 50
∆p = 0.2 - 1.0
∆p = 0.3 - 2.0
DN 15 - 50
∆p = 0.2
∆p = 0.5
AVP, AVP-F / 73695010
AVP-F (PN25)
DN 15 - 50
∆p = 0.2
∆p = 0.5
AQ09858645487201-000302| 1
