[24]
TUNING BY CHANNEL OR FREQUENCY
Switches tuning mode between channel and frequency. In channel mode the
tuning frequency is defined by the active channels table (CCIR, ...).
Key number 0 to enter numeric data.
[25]
AUTO ID/ EXPLORER
Activates the automatic identification function (short pulsation):
The instrument will try to identify the signal under test.
First it recognises whether the signal is an analogue channel or a digital one.
If the channel is analogue, it determines the television standard of the signal
detected.
When the signal is digital, it analyses the modulation type: DVB-T / DVB-T2 /
DVB-C / DVB-S / DVB-S2 and all the associated; parameters such as the
carriers 2k-8k, the symbol rate, the code rate, etc and it tries to lock to the
signal.
In the spectrum analyser and measurements mode, it appears on screen the
name of the network and the orbital position (only in satellite band).
Activates the band exploration function (long pulsation):
The meter explores the entire frequency band to identify the analogue and
digital channels present.
Page 26
USER'S MANUAL. TV EXPLORER HD +
Figure 5.- Top panel view.
30
12/2011
