Measure
Initio 2 conductivity meter
Ref : 701 653
Example with the Foxy
The parameter settings are complete, the displayed magnitude is now the conductivity with
symbol �� and unit is mS/cm.
4.2 Jack
The 3.5mm jack is used for example to connect the Initio 2 to a Groomy
181 000). The output voltage varies between 0 and 5V. We have:
5. WIFI communication
The WIFI module (ref 451 470) is used to display Initio 2 data, for example on a tablet.
5.1 Installing the WIFI module
The WIFI module is installed when the Initio 2 is switched off.
5.2 Display on tablet
Once the WIFI module has been installed, the tablet has to be configured:
ENGLISH
®
console
- Start the Generalist
- Put the icon for a direct input
Select the ±5�� range
-
- Fill in the customisation tab as a function of the range, for example:
- Click on the diskette to save the parameter settings
- -20°C corresponds to 0V
- 120°C corresponds to 5V
- Raise the Initio 2 stand
- Remove the back by sliding it downwards
- Put the WIFI module into place, replacing the back
- Push the module all the way into place until it click fits. It must be possible to retract
the stand without forcing
Press the Menu "button"
-
- Select Parameters
on the required axis
14
®
interface (ref
