Measure
Initio 2 conductivity meter
Ref : 701 653
You can only save one acquisition.
acquisition.
2.6.4 Transfer data to a computer
Once the acquisition is complete, you can transfer the data onto a computer for processing:
Data are then displayed on the screen. Do a right click on the graph to access the different
graphic tools.
3. Data display
You can display data in the form of a table or a graph at any time. Simply press the Return
key (2). You thus change in sequence from the measurement to the table and then to the
graph. You can continue the acquisition regardless of what is displayed.
The table or graph will be displayed in full screen after 5 seconds without taking any action.
Turn the knob if you want to obtain the associated functions once again.
The arrows at the bottom right in the table are used to move through the rows of the table.
4. Analogue outputs
The Initio 2 has analogue outputs on banana connectors and on the 3.5 mm jack.
4.1 Banana connectors
ENGLISH
Press the Menu "button" (4)
-
- Select File and validate
- Select Save
- Install the Initio 2 software available at address
- Connect the Initio 2 to the computer using the USB-��USB cable
- Open the Initio 2 software
- Load the saved acquisition by clicking on the icon:
- Connect the Initio 2 to an ExAO interface provided with direct inputs using banana
cables
- Configure the direct input depending on the range:
o
0-2ms/cm
o

0 mS/cm corresponds to -5V

2 mS/cm corresponds to +5V
o

0 mS/cm corresponds to -5V

20 mS/cm corresponds to +5V
Select Open to open the most recently saved
www.jeulin.com/Initio 2
13
