Operation instructions
• Display
When electrify the refrigerator, the display screen
will total display for 3 seconds. Meanwhile the
starting up bell rings and then the screen enters the
normal display of the operation.
The first time for using the refrigerator, the default
set temperature of refrigerating chamber and
freezing chamber is 4° C/-18 °C respectively.
When the error occurs, the display shows the error
code (see next page); during normal running,
the display shows the set temperature of the
refrigerating chamber or freezing chamber.
Under normal circumstances, if there is no operation
on display panel or door opening action within 30s,
then the display is lock, and the sate
• Lock /unlock
In the unlocked state, long press the lock button
for 3 seconds, enter the lock state.
The logo goes outand buzzer sounds, it means
the display panel is locked, at this time, button
operation cannot be implemented;
In the locked state, long press the lock button
for 3 seconds, enter the unlocked state.
The logo lights up and buzzer sounds, it means
the display panel is unlocked, at this time, button
operation can be implemented.
• Temperature setting of refrigerating chamber
Press temperature zone selection button
to choose the setting temperature
zone of refrigerating chamber, and then press
to adjust the setting temperature of refrigerating
chamber. The temperature setting range for
refrigerating chamber is 2°C ~ 8°C.
• Temperature setting of freezing chamber
Press temperature zone selection button
to choose the setting temperature
zone of freezing chamber, and then press
to adjust the setting temperature of freezing
chamber. The temperature setting range for
refrigerating chamber is -24°C ~ -16°C.
• Temperature setting of variable temperature
chamber
Press Variable temperature button to adjust the
setting temperature of the chamber, the adjusting
range is Fruit / vegetable, drink and meat.
• Mode setting
Set the Super cooling mode: after the temperature
of the refrigeration room is adjusted to 2°C, press
the temperature down button " " to enter the
super cooling mode. In the super cooling mode,
the temperature of the refrigerating chamber is
automatically set to 2°C.
Exit the Super cooling mode: press the
temperature up button " " to exit the super
cooling mode or automatically exit the super
cooling mode after 6h.
After exiting the super cooling mode, the
temperature of the refrigerator will automatically
return to the temperature set before the super
cooling mode.
Set the super freezing mode: after the temperature
of the freezing chamber is adjusted to -24°C,
press the temperature down button " " to enter
the super freezing mode. In the super freezing
goes out. mode, the temperature of the freezing chamber is
automatically set to -24°C
Exit the super freezing mode: press the
temperature up button " " to exit the super
freezing mode or automatically exit the super
freezing mode after 32h. After exiting the super
freezing mode, the freezing chamber temperature
will automatically return to the temperature set
before the super freezing mode
According to IEC62552:2007, the test condition
as follow: Start the super freezer mode in
advance, and wait when the fridge enters
automatic defrosting after 18 hours, and then
apply the freezer load. The maximum defrosting
time is 72 hours and the minimum is 12 hours
at 32°C. Recommended setting : refrigerated
chamber 4°C freezing chamber -18°C.
or
The quick-freezing function is designed to maintain
the nutritional value of the food in the freezer. It can
freeze the food in the shortest time. If a large
amount of food is frozen at one time, it is
recommended that the user turn on the quick-
or
freezing function and put the food in. At this time,
the freezing speed of the freezer compartment
is increased, which can quickly freeze the food,
effectively lock the nutrition od the food, and
facilitate storage.
• Sabbath mode
Unlock the fridge, and then press the " " and the
lock button at the same time for 4 seconds, into the
Sabbath mode. Press any key to exit.In this mode the
fridge status:
a. Display control board and lights remainoff, and
no alarm.
b. The refrigerator cools normally.
c. Within five minutes of the door pning,compressor,
fan motor status does not change.
