Operating Instruction
General
9 General
9.1 Transport Damage
All deliveries are to be insured by the
customer. We must turn down any possible
claims concerning transport responsibility.
Our responsibility is restricted to the hand -
over of the machine in brand-new condition to
the shipping agent. Should you discover any
damage to the machine, do not use it and
contact the shipping agent concerning the
damage.
9.2 Warranty
Every machine is covered by a 12
months warranty against material faults
and incorrect assembly. The warranty
covers all parts that are returned post
free within twelve months for inspection.
The parts will then be inspected by us to
determine whether the parts
were damaged under normal use.
The warranty will be declared void if
the parts are found to have been over-
loaded, handled incorrectly or that re-
placement parts have been assembled
incorrectly.
9.3 Ordering of spare parts
Please give the following details when
ordering;
Type:
Load:
Year of construction:
Serial Number:
Part description:
Order Number:
The address for ordering is to be found
on the cover of this operating instructions.
10 Appendix
Dimension Sheet
Mechanics KT100
Useful load 1000 kg
Type of load Surface load
Overall height 635 mm
Useful lift 1330 mm
Table top dimensions 5 x 1260 x 740 mm
Smooth sheet metal
Lift per pedal stroke approx. 12 mm
Lengthwise dis- ± 20 mm
placement
Lengthwise dis- ± 20 mm
placement
Inclination ± 2°
Wheels dia. 200 mm
Weight approx. 290 kg
KT100XT with extract
Operating pressure max. 220 bar
Oil volume 1.4 l
Type of oil Bio oil
Hydraulic cylinder 2x dia. 40 x 450 mm
stroke
Hydraulics
Useful load 1000 kg
Type of load Surface load
Overall height 670 ± 20 mm
Useful lift 1330 mm
Table top dimensions 5 x 1260 x 740 mm
Smooth sheet metal
Lift per pedal stroke approx. 12 mm
Lengthwise dis- ± 20 mm
placement
Lengthwise dis- ± 20 mm
placement
Inclination ± 2°
Wheels dia. 200 mm
Weight approx. 310kg
Hydraulics
Operating max. 220 bar
pressure
Oil volume 1.4 l
Type of oil Bio oil
Hydraulic cylinder 2x dia. 40 x 450
mm stroke
