Printer at a glance

Paper support
Front cover
e n
o p
ll to
p u
Control panel
Manual single sheet feeder closed

Printer in fanfold paper mode

Mantenimiento Periféricos Informaticos C/Canteras, 15 28860 Paracauellos de Jarama (Madrid) Tel: 00 34 917481604 Web: https://mpi.com.es/
Top cover
e n
o p
ll to
p u
Power inlet and
fuse
Power switch Tear edge
Bottom cover
Rear cover

Printer in single sheet mode

e n
o p
ll to
p u
Tractor 1
Printer at a glance
Ribbon cassette
Latches
Printhead
Interface connector
Manual single sheet feeder open
5
