9.4 Making cross cuts (Fig. 14)
Always use the parallel stop (7) and the angle stop
(14) when making cross cuts.
Workpieces must not exceed a maximum length of
160 mm between the parallel stop (7) and the blade
(4), and a maximum width of 70 mm.
Slide the angle stop (14) into the stop rail (25) of
the parallel stop (7).
Adjust the parallel stop (7) to the required length
of the workpiece and clamp in place.
Place the workpiece in front of the
angle stop (14).
Switch on the saw and, with the help of the push
stick (3), push the angle stop (14) together with
the workpiece along the stop rail (25) into the
blade (4).
Switch off the saw when you have finished the
cut.
10. Maintenance
Remove dust and dirt regularly from the
machine. Cleaning is best done with compressed
air or a rag.
Never use caustic agents to clean plastic parts.
11. Orders for replacement parts
Please quote the following information on all orders
for replacement parts:
Type of product
Article number of the product
ID number of the product
Replacement part number of the part required
