Product Information: Cordless Impact Wrench
Product Safety Information
Intended Use:
This Cordless Impact Wrench is designed to remove and install threaded fasteners.
⚠
WARNING: Read all safety warnings, instructions, illustrations, and specifications provided with this power tool. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
• Responsibly recycle or dispose of batteries. Do not puncture or burn batteries. Improper disposal may endanger the environment or cause
personal injury.
• Only use tools with appropriate voltage Ingersoll Rand batteries and charger. Use of any other batteries may create a risk of fire, personal
injury or property damage.
For additional information, refer to Cordless Impact Wrench Safety Manual Form 04581146, Battery Charger Safety Information Manual
Form 10567832, and Battery Safety Information Manual Form 10567840.
Manuals can be downloaded from ingersollrand.com
IQV Power Control System
The intelligent control management system on this model can be adjusted with the power regulator. Select power mode by turning the dial at the
back of the tool and align the notch with the desired setting. Each mode provides intelligent power control in Forward and full power in Reverse.
Impact wrenches are not torque wrenches. Connections requiring specific torque must be checked with a torque meter after fitting with an
impact wrench. Improperly torqued fasteners may loosen and cause injury.
Product Specifications
Voltage
Tool Model
V, DC
Type
W7153
20
Square
Tool Model
Direction
Forward
W7153
Reverse
† K
= 3dB measurement uncertainty
pA
‡ K
= 3dB measurement uncertainty
wA
* K = Vibration measurement uncertainty
Sound and vibration values were measured in compliance with internationally recognized test standards. The exposure to the user in a
specific tool application may vary from these results. Therefore, on site measurements should be used to determine the hazard level in that
specific application.
TL-W7153-LIK_ed2
Mode
Name
Hand Tight
Wrench Tight
Half Power
Max. Power
Impacts per
Drive
Minute
Size
bpm
1/2"
2,450
Intelligent Power Control
Mode
Name
Hand Tight
Wrench Tight
Half Power
Max. Power
ALL
WARNING
Description
Torque-limiting, Automatic Shut-off
Torque-limiting, Continuous Run
Maximum Torque, Continuous Run
WARNING
Sound Level dB(A)
(EN 62841)
† Pressure (L
)
‡ Power (L
p
95
106
No Load Speed
600
1,000
0-1,450
0-1,900
Conforms to UL STD. 62841-1 and 62841-2-2.
Certified to CSA STD. C22.2 No. 62841-1 and 62841-2-2.
WARNING
Vibration (m/s
)
2
(EN 62841)
)
Level
*K
w
17.0
3.7
Max. Torque
Shut-off
ft-lb (Nm)
Refer to Figure A
Refer to Figure B
530 (720)
-
1000 (1360)
EN
Battery
Model
BL2022
4004004
EN-1
