4- Exploded view / Parts list / Assembly
3
1 2
15
14
* Not all the accessories illustrated or described are included in standard delivery.
5- Presentation of the product / characteristics
Type CSC18BD.9 (CSC-designation of machinery, representative of circular saw)
Voltage
No load speed
Bevel capacity
Max. cutting capacity
Machine weight
NOISE INFORMATION
A weighted sound pressure：L
K
= 3 dB(A)
pA
A weighted sound power：L
K
= 3 dB(A)
wA
Wear ear protection.
ORIGINAL INSTRUCTIONS
4
5
6
9
10
13
11
12
at 45
at 90
= 82 dB(A)
pA
= 93 dB(A)
wA
SAFETY AND OPERATING MANUAL
1.
2.
3.
4.
5.
8
6.
7
7.
8.
9.
10. 24t cutting blade
11. Blade bolt
7
12. Lower blade guard
13. Lower guard release lever
14. Vacuum adaptor
15. Base plate locking knob
o
o
35
Battery pack*
Battery pack release button*
Handle
On/off switch
Lock-off button
Front handle
Parallel guide
Parallel guide lock knob
Base plate
0-57 degree
18V
5800 /min
47.5 mm
67.5 mm
3.168 kg
