ENG USER MANUAL
Thank you for choosing the products of Armytek.
Please read this manual carefully before using the flashlight.
Specifications
1. Headlamp: simple one-hand operation, reliable headmount. Solid
body without long wires, weak rubber connectors and unnecessary
boxes. The flashlight is easily installed, removed and 180° rotatable in
the mount
2. Every Day Carry light: compact design, convenient side button,
special matt anti-abrasive finish without rough knurling. Robust
removable steel clip and strong built-in tail magnet
3. Sports flashlight: body made from durable and lightweight
aircraft-grade aluminium, improved shock resistance, constant light
without flickering. Multiple variants of installation, optional accessories
for mounting on sporting gear
4. Keychain light: compact and lightweight for even more comfortable
carry in a pocket, hole for keyring or lanyard in the tailcap
• Pro Multicolor temperature, battery level and state indication
Model
Optics
Brightness stabilization type
Light output
Peak beam intensity
Hotspot : Spill
Beam distance
Modes, light output and runtimes (measured
with 18350 Li-Ion 900 mAh battery until the
light output drops to 10% of the initial value)
Power source
Time of charging (18350 Li-Ion 900 mAh battery)
Length/Body diameter/Head diameter
Weight without/with battery
Ingress protection, Submersion and Impact resistance
X All the above specifications are test results based on ANSI/PLATO FL 1-2019 Standard. The data may vary due to environment, heat dissipation and other factors.
2 ENG USER MANUAL WIZARD C1 PRO
Wizard C1 Pro (white light)
TIR
DIGITAL (CPU brightness control)
1000 lm
2510 cd
70°:120°
100 m
Turbo2
1000 lm/55 min (500 lm after 5 min)
Turbo1
440 lm/1 h 24 min
Main3
210 lm/3 h
Main2
100 lm/6 h 40 min
Main1 40 lm/16 h 30 min
Firefly3 7 lm/2.5 d
Firefly2 2 lm/8 d
Firefly1 0.11 lm/60 d
Strobe3 1000 lm/10 Hz/1 h
Strobe2 1000 lm/1Hz/2 h 20 min
Strobe1 100 lm/1 Hz/32 h
1x18350 Li-Ion
1 h
77 mm/20.4 mm/33 mm
54 g/79 g
IP68. Depth up to 10 m for 5 h. Height up to 10 m
• Convenient wide beam of fully upgraded optical system, steel bezel
and tempered glass with anti-reflective coating for protection of the
TIR-lens
• Innovative technology allows using any standard 18350 Li-Ion
battery. Full protection against short circuit even in case of contact
between magnetic connector and metal objects
• Active real-time temperature control to prevent overheating above
+58 °C
• Total protection from water, dirt and dust in accordance with IP68
standard — flashlight continues to work even after submersion at
10 meters depth. Withstands fallings from up to 10 meters
• Robust and water resistant magnetic connector
Wizard C1 Pro (warm light)
930 lm
2430 cd
99 m
930 lm/55 min (465 lm after 5 min)
410 lm/1 h 24 min
195 lm/3 h
93 lm/6 h 40 min
37 lm/16 h 30 min
6.5 lm/2.5 d
1.9 lm/8 d
0.1 lm/60 d
930 lm/10 Hz/1 h
930 lm/1Hz/2 h 20 min
93 lm/1 Hz/32 h
REV_00-0002
