WARRANTY
Display of state of the heat demand determination.
For the calculation of the heat demand the following states are defined:
•
OAT measurement: Measurement from the sensor is available (local sensor or wireless sensor,
usually only shortly after power-up or if the weather forecast data from the internet have not yet been
received)
•
OAT now: Current single value from the outside tempera-ture measurement
•
Weather now: Current single value from the weather forecast
•
Weather future: Time series from the weather forecast with stored values from the past
The possible messages of the two outside tempera-ture sources (OAT measurement series and weather
series) are:
•
(not in use): Source was not needed (e.g. sensor not needed if weather forecast complete)
•
No values: Source is faulty (sensor defective, no weather forecast)
•
Single value: Source returns a single value for the current point in time
•
Time series: Source returns a time series for the past and possibly the future
Outside temp. measured
Display of the currently measured outside temperature in °C.
Outside temp. effective
Display of the effective outside temperature in °C. The effective outside temperature is the weighted aver-
age of the outside temperature of the last few hours (weather forecast data and sensor measurements).
Due to the averaging (time factor adjustable via "ground characteristic"), this temperature may deviate
from the real outside temperature. The effective outside temperature serves as the basis for activating the
pre-heating control mode or the base temperature mode.
Alarm delay
Adjustment of the alarm delay. An alarm will only be passed on if this time has passed.
Factory setting: 60 min
Alarm relay inverted
Adjustment of the alarm relay's operating mode.
24
