WARRANTY
CONNECTION VIA TGN
When several devices in a system are connected, they all need to be connected to each other via the
TGN bus so that they can exchange data with each other.
Setup exp. channel
The 1873-ESM is delivered with a fixed channel 1 and the 1875-ESM with a pre-set channel 2. In case of
a two-channel system, no further adjustment of the channels is required. Only the channels 2 to 8 can be
assigned to the 1875-ESM, since channel 1 is always reserved for the 1873-ESM.
After changing the channel of one or more 1875-ESM(s), the entire system must be restarted. In addition,
the active channels that no longer exist must be deregistered under Installer - Config. modules - Delete
registered channel. You can check the channels registered on the 1873-ESM under Installer - Information
- Registered channels.
During the configuration of a Multi Channel system with more than two channels, only one 1875-ESM
may be connected to the 1873-ESM via TGN. The next device must not be connected and configured
until the configuration for one device has been completed. If more than one device is connected at a
time, the configuration will fail.
Factory setting: 2
FIRST START
When the device is started for the first time, a start screen is displayed in which the menu language must
be selected. The default language is German, which must be confirmed or changed.
During initial startup, all parameters must be set under the menu items mentioned above.
These are:
Application
11
