6.3.

Description of the registers

Register values can be updated with the ATSn=m<cr> command and displayed with the ATSn?<cr> command.
On power-up, the transmitter-receiver's previous configuration is restored from the E2PROM (non-volatile) to
the RAM. The registers are located in the RAM registers, all changes are made in the RAM registers: in order to
save the current register configuration, the AT&W<cr> command must be used (otherwise the updated parame-
ters will be lost if the power is cut).
The parameters are divided into 2 types: read only (R) or read/write (R/W).
Type Register
Radio
manage-
ment
R/W S200
R/W S202
R/W S204
R/W S217
R/W S218
R S230
R/W S231
208210A_UG_V1.0_ARFx3-PRO
Function Description
Channel Radio channel for the 869 MHz version:
number 1 and 3: wide band channels
18 to 85: narrow band channels
Command Automatic exit from command mode 0: (no
mode auto- specific management), exit from command
matic exit mode only when an ATO command is
issued.
From 1 to 60: timeout in seconds.
-> if no activity (no character, no command
received) is detected in command mode
during the programmed timeout, the system
will exit command mode. The module
returns to transmitter-receiver mode.
Preamble Preamble length in ms from 4 to 50
length
Serial timeout Serial timeout before the start of radio trans-
for radio mission, in ms from 3 to 240
Radio frame Size of the radio frame (from 1 to 240)
length When the limit is reached:
• the transmitter-receiver sends a radio
frame
• the RTS signal is enabled only if the
module is operating in addressed mode
RSSI level Displays the reception level for the last mes-
sage received.
Response: S230=-xxx dBm<cr><lf> with xxx
decimal value.
Example S230=-80 dBm
RF exit level Adjusts the RF exit level
0
1
2
3
53-PRO 43-PRO 33-PRO
14dBm 10dBm 10dBm
20dBm 14dBm
24dBm 17dBm
27dBm
Default value Note
84 3
0
20 4
3 1
128
None
27/24dBm for the
ARF53-Pro
(note: USB versions are
set to 24dBm in order
to limit the current to
450mA)
17bBm for the
ARF43-PRO
40
