202
Attaching pin
A shoulder strap can be attached to this pin.
6.7 - FUNCTIONS
SWITCHES
S281
Not used
S282
Not used
S280
Selection :
Y C
C
/R G B in the EFP configuration
R
B
with the CCU 1625:
• without
APCM
determines the type of video at
the CCU output,
THOMSON TTV 1657D
User manual
Functions of internal master board switches
OF
INTERNAL
)
S283 (component side)
CA25/VTR selection:
option,
Inside
Switch
CA25
VTR
Chapter 6 - Rear adapter (CA25)
MASTER
S23
SYNC G : ON/OFF
• if the CA25 is connected to a
CCU: CA25 position,
• if the CA25 is connected to a
VTR: VTR position.
BOARD
B1657D902D
