166
3.2.3 - General description
"ON AIR 1"
indicator
light
Cover attaching screws
' ! " #
THOMSON TTV 1657D
User manual
Socket for connection of camera
!
" # $ % &
Chapter 3 - Viewfinders
14 cm viewfinder old generation
1
VIDEO IN
VIDEO GND
9
2
N.C.
10
SCK
3
N.C.
11
ON AIR1
4
SS (Slave Select)
12
N.C.
5
MOSI
MISO
13
6
N.C.
N.C.
14
POWER IN (11V/17V)
7
N.C.
15
8
POWER GND
Mounting attaching
lugs
1 kOhm/75 Ohm switch
(to be set to 75 Ohms)
B1657D902D
October 2001
