196
6.3 - CONNECTOR DEFINITIONS
1 - VTR/CCU
2 - MICROPHONE
INPUT
3 - INCOM HEAD
SET
4 - POWER DC IN
THOMSON TTV 1657D
User manual
*
$
)
#
"
!
%
'
$
&
#
%
"
!
"
'
!
&
Socket:
TYPE : SRC B 02A 21-26P
REF : 91.583.192
Plug:
TYPE : SRC B 06 A
REF : 91.592.584
!
Socket:
TYPE : XLRNCF30-V
3
2
4
1
5
0
(NC)
6
Socket:
TYPE : TUCHEL 2121
Plug:
REF : T2121000
"
!
Socket:
TYPE : XLR 4-32F515-01
Chapter 6 - Rear adapter (CA25)
Connector definitions
ENCODED VIDEO
ENCODED VIDEO GND
Y/G GND
Y/G VIDEO
R-Y/R VIDEO
R-Y/R GND
B-Y/B VIDEO
B-Y/B GND
MIC OUT X
MIC OUT Y
LONG CABLE/MIC GND
VTR ST ST OUT
BATT IND/DATA
ALIM CONT
REC TALLY
GEN.LOCK VIDEO GND
INCOM GND
PB VIDEO IN
PB VIDEO GND
AUDIO MONITOR/BTR SAVE
GEN.LOCK VIDEO IN
COLOUR FRAME OUT
INCOM.X
INCOM.Y
+12V POWER CABLE
GND (POWER)
!
Level: - 60 dB
Phantom supply:
+ 9 V
4
- MICRO
3
+ MICRO
2
GND MICRO
6
GND EAR
5
EAR LEFT
1
EAR RIGHT
ALIM
J40
+ BATT
4
3
NC
2
NC
GND
1
(0V)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
A
B
(11/17V=)
B1657D902D
October 2001
