English
Water Outlet Temp.
b2 : 5.0 C°
Pump
:
Comp 1:
Comp 3:
Comp 2:
Comp 4:
After few minutes return to the probe B1.
4.4.2 Visualization of digital outputs/analog inputs
(P5)
Press the button
for several times to view the digital
outputs and the analog inputs available
DIGITAL OUTPUT
Pump
:
Compressor 1 :
Compressor 2 :
Compressor 3 :
Compressor 4 :
DIGITAL OUTPUT
A/Freeze
:
Unit Status
:
Gen.Alarm
:
Fan 1
:
Fan 2
:
Fan 3
:
ANALOG INPUT
b1 : 10.0 C°
b2 : 7.0 C°
b5 : 20.0 C°
P1 : 10.0 bar
P2 : 10.0 bar
Hyperchill 310-360
4.5 Parameter settings
General
There are three levels of protection for parameters:
a) DirE (D): with immediate access, for user access;
b) User (U): password protected: for sevice technician;
C) Fact (F): factory parameters don't changeble.
4.6 Direct parameter (DIrE)
(P2)
Press the button
to enter in the "main" menu.
(P5)
Press the button
to select "DIrE"
(P6)
Press the button
to confi rm.
(P5)
Press the button
to scroll the parameter.
(P6)
Press the button
to enter
(P4)
(P5)
Press the button
or
(P6)
Press the button
to confi rm
4.6.1 Direct parameter
PARAMETER
CODE
Temperature control set point
SEt
Temperature control differential
dIF
High temperature alarm
HA1
Low temperature alarm
LA1
Chiller hour counter
HU
Compressor 1 operation hour
H1
counter
Compressor 2 operation hour
H2
counter
Compressor 3 operation hour
H3
counter
Compressor 4 operation hour
H4
counter
4.7 Service parameters (USER)
4.7.1 Machine parameters
PARAMETER
Unit of measurement
Unit address
On/off enabling by supervisor
Remote on / off enabling
(see para. 4.7.1.1).
Alarm relay management (see
para. 4.7.1.2)
Digital output 3 confi guration
Compressor 1 enabling
Compressor 2 enabling
Compressor 3 enabling
Compressor 4 enabling
Chiller hour counter alarm
to modify.
threshold
Compressor 1 hour counter
threshold
Compressor 2 hour counter
threshold
TYPE DEFAULT
Compressor 3 hour counter
D
7.0
threshold
D
4.0
Compressor 4 hour counter
D
60.0
threshold
D
-20.0
Set point lower limit
D
-
4.7.1.1. Remote On / Off mode
0
Remote On/Off disabled
D
-
Remote On/Off enabled together with local On/Off
1
D
-
Remote On/Off only, local On/Off disabled
2
4.7.1.2. Alarm relay management
D
-
Relay normally deactivated, excited by an alarm.
0
Relay normally excited (also with control OFF), deacti-
D
-
1
vated by an alarm.
Relay normally excited (only with control ON), deacti-
2
vated by an alarm or with control OFF.
6/10
CODE TYPE DEFAULT
C-F
U
0
U
Adr
1
SUP
U
0
rE
U
0
rAL
U
0
Ud3
U
1
Abc1
U
1
U
Abc2
1
Abc3
U
1
Abc4
U
1
tHU
U
0
tH1
U
0
tH2
U
0
U
tH3
0
U
tH4
0
U
LIS
5.0
