S o :
tep ne
Turn off water feeding the appliance and ensure
water-consuming appliance is turned OFF.
Select appropriate space to install the filtration
system. The water filter should be mounted upright
on a vertical surface without obstructions; leaving a
minimum of 6" space below the system for cartridge
change outs. System measurements are shown below.
S t :
tep wo
Prepare space for the system:
1. Select appropriate space to install the filtration system. The water filter
should be mounted upright on a vertical surface without obstructions;
leaving a minimum of 6" space below the system for cartridge change outs.
System measurements are shown below.
2. Identify incoming water line. Filtration System should be connected to cold
water only.
NOTE: For post mix, verify the water line selected is the one entering the
3. Cut water supply lines.
NOTE: If hard copper plumbing is present, use only lead-free solder and protect
4. If an existing filter needs to be removed, terminate both ends of plumbing
with appropriate fittings.
NOTE: Follow appropriate plumbing codes.
VERIFY APPROPRIATE SPACE IS AVAILABLE FOR SYSTEM
13"
carbonator - NOT the carbonated water line. If a water booster pump
is present, the Filtration System should be installed after the water
boost before the carbonator.
filter housing from heat. Do not solder within 12" of plastic parts.
6"
Width x Height (head + cartridge + clearance) x Depth
IC600 13" x (9" + 10" + 6") x 10"
IC614
13" x (9" + 14" + 6") x 10"
8
Single Head
