Elevator Light Grid AL20/AL40

Dimensions

25 Dimensions
18.9
18.9
Detail X
26 Contact
If you have questions or suggestions about this product, please contact our customer
service team. They will be happy to help you with professional expertise.
Pepperl+Fuchs GmbH
Lilienthalstraße 200
68307 Mannheim
Phone: +49 621 776-4411
Fax: +49 621 776-274411
E-mail: fa-info@pepperl-fuchs.com
16
2000
Pos. of reed relay/
magnet contact at 206 mm
Pos. of 7-segment display
at 226 mm
Pos. of reed relay/
magnet contact at 206 mm
Pos. of 7-segment display
at 226 mm
Detail X
AL2012-... and AL4012-...
AL2016-... and AL4016-...
Aluminum Aluminum
profile 12 mm profile 16 mm
12.4 16
