VUE D'ENSEMBLE
VUE D'ENSEMBLE
7
8
9
10
11
1.
En marche / Indicateur de charge LED (Paragraphe 2.6)
2.
Témoin d'erreur LED (Paragraphe 2.6)
3.
Témoin LED d'erreur de câblage (Paragraphe 2.6)
4.
Bouton MENU (Paragraphe 2.5)
5.
Afficheur LCD (Paragraphe 2.6)
6.
Port technique (ne pas utiliser. A usage du service technique d'usine seulement.)
7.
Connecteurs MasterBus (Paragraphe 3.6)
8.
Prise pour sonde température (Paragraphe 3.6)
9.
Borne terre (Paragraphe 3.6)
10. Capteur de tension de batterie (Paragraphe 3.6)
11. Bride de câbles (Paragraphe 3.6)
12. Entrée solaire (« Solar ») (Paragraphe 3.6)
13. Sortie batterie (« Battery ») (Paragraphe 3.6)
14. Capot du bornier (Paragraphe 3.6)
15. Plaque d'identification (Paragraphe 1.4)
Figure 1 : vue d'ensemble
2
6
12
13
3
2
4
1
15
14
Juin 2015 / Solar ChargeMaster 60 MPPT-MB / FR
