Introduction
Thank you for purchasing this Silverline product. This manual contains information necessary
for safe and effective operation of this product. This product has unique features and, even
if you are familiar with similar products, it is necessary to read this manual carefully to
ensure you fully understand the instructions. Ensure all users of the product read and fully
understand this manual. Keep these instructions with the product for future reference.
Description of Symbols
The rating plate on your tool may show symbols. These represent important information about the
product or instructions on its use.
Wear hearing protection
Wear eye protection
Wear breathing protection
Wear head protection
Wear hand protection
WARNING: To reduce the risk of injury, user must read instruction manual
Caution!
DO NOT use with compressed gas cylinders!
Conforms to relevant legislation and safety standards.
Environmental Protection
Air tools should not be disposed of with household waste. They contain traces of
oil and other lubricants. Please recycle where facilities exist. Check with your local
authority or retailer for recycling advice.
4
Original Instructions
Technical Abbreviations Key
n
No load speed
0
psi Pounds per square inch
bar Metric unit of pressure
L/min Litres per minute
cfm Cubic feet per minute
Ø Diameter
min Operations per minute
-1
BSP British Standard Pipe (thread)
dB(A) Decibel sound level (A weighted)
m/s Metres per second squared (vibration magnitude)
2
Specification
Maximum operating pressure: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.3bar (90psi)
Air consumption:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113L/min (4cfm)
Air inlet: . . . . . . . . . . . . . . . . . 1/4" BSP, supplied with two male airline quick connectors
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .(EN-6 'UK' and EQ-4 'European' types)
No load speed: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15,000min
Backing pad: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ø50mm
Orbit variation: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3mm
Weight:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.6kg
As part of our ongoing product development, specifications of Silverline products
may alter without notice.
Sound and vibration information:
Sound pressure L :. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96dB(A)
PA
Sound power L : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107dB(A)
WA
Uncertainty K: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3dB
Weighted vibration a : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11.8m/s
h
Uncertainty K: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5m/s
The sound intensity level for the operator may exceed 85dB(A) and sound protection
measures are necessary.
Sanding Safety Warnings
WARNING: Read and understand the safety instructions before installing, operating, repairing,
maintaining, cleaning, changing accessories on, or working near this tool. Failure to do so can result
in serious injury.
Save all warnings and instructions for future reference.
WARNING: This appliance is not intended for use by persons (including children) with reduced
physical or mental capabilities or lack of experience or knowledge unless they have been given
supervision or instruction concerning use of the tool by a person responsible for their safety.
Children must be supervised to ensure that they do not play with the tool.
• Only qualified and trained users should install, adjust, or use the tool.
• Do not modify the tool. Modifications can reduce the effectiveness of safety measures and
increase the risks to the user.
• Do not discard the safety instructions; give them to the user.
• Do not use the tool if it has been damaged.
• Inspect the tool periodically to verify that the ratings and markings required by ISO 11148
(detailed in the Description of Symbols) are legibly marked on the tool. The user (and employer
if appropriate) should contact the manufacturer to obtain replacement marking labels when
necessary.
• Compressed air can cause severe injury.
