I N S TA L L I N G M . 2 S S D M O D U L E (O P T I O N A L )
1. Locate the M.2 SSD slot and insert an M.2 SSD
module into the slot at a 45 degree angle.
2. Gently press down on the M.2 SSD module, and
install the screw.
F R O N T PA N E L
1. Power button
2. Memory card reader (SD/SDHC/SDXC)
3. USB 3.1 port
4. Microphone jack
5. Headphone/Audio Out jack
6. USB 3.1 Type-C port
R E A R PA N E L
1. WiFi antenna connectors
2. USB 3.0 ports
3. DP ports
4. HDMI port
5. DVI port
6. LAN (RJ45) ports
7. Power inputs (DC19.5V)
S E T T I N G U P YO U R ZOTAC Z B OX
1. Connect antenna for WiFi
2. Connect USB 3.0 devices
3. Connect DP displays
4. Connect HDMI displays
5. Connect DVI displays
6. Connect to home networks
7. Connect power cable
8. Turn on the system
