ILLUSTRATIVE GUIDE
[A]
EN
[C]
9
8
DESCRIPTION OF THE APPLIANCE
1. Heated mattress cover connector
2. Control unit connector
3. Mains socket
4. Rating Label
5. Heated mattress cover
6. Timer selector
TECHNICAL DATA
TYPE R7609
220-240 V 50/60 HZ 2x150 W
TYPE R7607
220-240 V 50/60 HZ 2x150 W
11
6
10
7
[B]
11
7. ON/OFF button
8. Temperature selector
9. Stand-by LED
10. Auto Shut Off Timer
11. Temperature LED
TYPE R7605
220-240 V 50/60 HZ 150 W
TYPE R7611
220-240 V 50/60 HZ 2x150 W
Temperature table
6 Fast Pre-heat
5-4 Medium Pre-heat
1-3 Continuous or all
night use
