12b)
Clack - Clack
Note
This function is only available with the transmitters MemoControl MC441 and MC411 from Becker Centronic control pro-
grams.
Every tubular drive can store switching times for one UP and one DOWN command.
If the sliding switch is set to "Clock" this roller shutter command is repeated every 24 hours.
The position of the manual/auto sliding switch is unimportant when programming the switching time. All previously stored switching times are
deleted accordingly.
1. Adjust the roller shutters, if necessary, until they are in the limit position opposite to the desired running direction.
2. Wait until the time at which the automatic control command is to be executed.
3. At the preset time activate the desired direction key and hold down until the roller shutter system stops briefly after approximately 6 seconds
and then moves unto the limit position.
4. Release direction key.
The tubular drive will automatically store the current time for this control command.
Note
Both switching times are always deleted in this process.
In order to delete the times the UP and DOWN control commands are to be triggered, press the STOP button for 10 seconds. This is acknowledged
by a double click of the tubular drive.
The switching times have been deleted.
12b) Activating the tubular drive programme mode with the radio switch
Slide the radio switch into the inner posi-
tion. If the radio switch is already in this
position, slide the switch outwards and then
back to the inner position again.
Now press the learn button of the new mas-
ter transmitter for 10 seconds.
Programming the switching times
Deleting the switching times
Action
The tubular drive goes into programme
mode for 3 minutes.
The tubular drive makes a "clack-clack"
sound to confirm.
The new master transmitter has been
programmed and the old master transmitter
has been deleted.
26
Operating Instructions
Response
