2 OVERVIEW
2.1 OVerVieW OF parent unit
1. Sound indicator LEDs
2. Talk-back button
3. Display (see section 2.3)
4. Power on/off
5. Decrease volume; also 'Down' but-
ton when programming the device
6. MENU
7. Loudspeaker
8. DC input for power adapter
9. Microphone (for talk-back feature)
10. Increase volume; also 'Up' button
when programming the device
11. Start/stop lullaby
12. LEDs (see section 2.5)
: Connection check
: Low battery/charging
2.2 OVerVieW OF BaBy unit
1 Temperature sensor (on rear of
baby unit)
2 Built-in nightlight (not visible
when device is switched off)
3 Display (see section 2.3)
4 Power on/off
5 Lullaby selection
6 Decrease volume
7 Start/stop lullaby
NUK Babyphone 10.256.267 (BM-200).indb 28
All manuals and user guides at all-guides.com
: Full Eco mode
Parent unit
Baby unit
8 Loudspeaker
9 Increase volume
10 Pager (to page the parent unit)
11 DC input for power adapter
12 Nightlight
13 Microphone
14 LEDs (see section 2.5)
: Power
: Low battery
