Whirlpool WED4985EW Instructions D'installation page 6

Back View
4"
(101 mm)
30 / "
1
4
(768 mm)
1 / "
1
4
(32 mm)
"
/ 4 / "
1 3
2 4
9 "
/
1 (121 mm)
4
(235 mm)
Installation spacing for recessed area
or closet
The dimensions shown are for the minimum spacing allowed.
Additional spacing should be considered for ease of
■
installation and servicing.
Additional clearances might be required for wall, door,
■
and floor moldings.
Additional spacing of 1" (25 mm) on all sides of the dryer
■
is recommended to reduce noise transfer.
For closet installation, with a door, minimum ventilation
■
openings in the top and bottom of the door are required.
Louvered doors with equivalent ventilation openings are
acceptable.
Companion appliance spacing should also be considered.
■
6
1 / "
1
4
(32 mm)
14 "
/
1
2
9 "
/
(368 mm) 1
4
(235 mm)
Installation Spacing
14" max.
(356 mm)
5 / "/0"
1
2
(140 mm/0 mm)
1"/0"
(25 mm/0 mm)
Recommended/Minimum spacing
Mobile home – Additional installation
requirements
This dryer is suitable for mobile home installations. The
installation must conform to the Manufactured Home
Construction and Safety Standard, Title 24 CFR, Part 3280
(formerly the Federal Standard for Mobile Home Construction
and Safety, Title 24, HUD Part 280) or the Canadian
Manufactured Home Standard CAN/CSA-Z240 MH.
Metal exhaust system hardware, available for purchase.
■
For further information, please reference the "Assistance
or Service" section of the "Use and Care Guide."
Special provisions must be made in mobile homes to
■
introduce outside air into the dryer. The opening (such
as a nearby window) should be at least twice as large
as the dryer exhaust opening.
For gas dryers mobile home installations:
Mobile Home Installation Hold-down Kit Part Number
■
W10432680 is available to order. For further information,
see "Assistance or Service" section in your "Use and
Care Guide."
3"/3"
(76 mm/76 mm)
48 in. 2 /48 in.
(310 cm 2 /
310 cm 2 )
18"/18"
(457 mm/
457 mm)
24 in. 2 /24 in.
(155 cm 2
155 cm 2 )
1"/1"
(25 mm/
3"/3"
25 mm)
(76 mm/76 mm)
2
2
/
