VIDEO ADJUST Screen
Adjustments are made on video signals.
Item
Selects the white balance adjustment function. The white
WHITE
balance can be adjusted manually or automatically for
BALANCE
light within the colour temperature range of 2500K to
8000K.
• ATW:
• AWC:
The "- - -" will appear during operation in the black-and-
white mode and any setting cannot be changed.
To adjust the colour level of the video signal.
COLOUR
• To make colours lighter ... Decrease the value
LEVEL
• To make colours darker ... Increase the value
[Set values: –5 to NORMAL to 5]
The "- - -" will appear during operation in the black-and-
white mode and any setting cannot be changed.
To adjust the contour enhancing level of the video signal.
ENHANCE
• To make the picture quality harder ... Increase the value
LEVEL
• To make the picture quality softer ... Decrease the value
[Set values: –5 to NORMAL to 5]
To adjust the pedestal level of the video signal.
PEDESTAL
• To brighten picture ... Increase the value
LEVEL
• To darken picture ... Decrease the value
[Set values: –5 to NORMAL to 5]
This is set when it is difficult to view a dark part of the
AUTO
image even if gain is boosted by the AGC (automatic gain
BLACK
control).
CTL
ON: When a black level of the image signal is low, a
OFF: AUTO BLACK does not function.
• When PEDESTAL LEVEL is set to 5, no function can
take place even if AUTO BLACK CTL is ON.
• When AGC MODE is set to OFF, no function can take
place even if AUTO BLACK CTL is ON.
All manuals and user guides at all-guides.com
Functions and set values
Auto-Tracking White Balance mode.
This automatically adjusts the white balance.
Auto White Balance Controll mode. When the
SET button is pressed, the adjustment
screen appears.
(
See page 37.)
MEMO
MEMO
pedestal level that becomes the standard of black
is automatically elevated, making it easier to view a
dark part.
MEMO
Initial value
ATW
NORMAL
NORMAL
NORMAL
OFF
E-31
