To do so, it is supplied with 3 connection cables:
1 connector-free cable for the power supply, the bus, the NMEA IN & OUT, the alarm output
1 LT8 cable for connection to the speedometer sensor
1 RCA cable for connection to the sounder sensor
The Multi S400 is part of the S400 advanSea family of navigation instruments, including
instruments for measuring speed, depth, and wind. They may be connected together to form
an integrated data system for a boat (see chapter 2.7).
1.2. Components supplied with your Multi S400
The Multi S400 comes with (as standard):
-
-
-
-
The Multi S400 does not come with sensors. You can order complete kits, or consult our
website www.advanSea.com.
You will also find a complete list of accessories at
1.3. Technical characteristics
Measurement characteristics
Sounder:
Speed:
Trip log:
Total log:
Battery voltage:
All manuals and user guides at all-guides.com
protective cover
user manual
warranty card
adhesive rear sealing joint for flush mounting
Measurement range: from 0.5 to 199 meters
Operating frequency: 200 kHz
Accuracy: ±0.1 meter up to 5.0 meters and ≤2% beyond 5.0 meters
(this accuracy is given for a constant sound speed in water of 1490
m/s)
Resolution: 0.1 from 0 to 19.9 and 1 beyond
Configurable offset: ±9.9 meters
Measurement range: from 0.0 to 60.0 knots
Speed ratio: fixed at 6.1 Hz/knots
Accuracy: ±1.0 knots up to 20.0 knots and ±5% beyond 20.0 knots.
Resolution: 0.01 from 0 to 19.99 and 0.1 beyond
Calibration possible on 2 measurement points (Slope and Offset)
Measurement range: from 0.00 to 655.35 kilometres
Resolution: 0.01
Measurement range: from 0 to 65535 kilometres
Resolution: 1
Measurement range: from 10.0V to 16.5V
Accuracy: ±0.2V
Resolution: 0.1V
