AIR DIAGRAMM
Torque Adjustment / Drehmomenteinstellung / Vääntösuunnan valinta / Ajuste de par torsión / Ρυθμιση ροπης / Naravnavanja
vrtilnega momenta / Val av rotationsriktning / Regolazione della coppia / Réglage du couple/ instelling draaimoment
Start
B
Free speed
Min
Model
1
2
[min-1]
[Nm]
CP2003
1,100
0.3 - 0.4
CP2005
1,100
0.3 - 0.4
CP2007
1,100
0.3 - 0.4
CP2008
1,100
0.3 - 0.4
CP2010
1,470
1.5 - 2
CP2011
1,000
1.5 - 2
A
A
B
Torque
Dimension
LxHxA
Max
3
4
[inch]
[Nm]
[mm]
7.7 x 0.59
1.1 - 1.5
197 - 15
7.2 x 5.6 x 0.67
3.2 - 4.3
182 x 143 x 17
9.8 x 0.59
3.2 - 4.3
250 x 15
10.8 x0.63
3.2 - 4.3
275 x 16
10.0 x 0.67
4.1 - 5.5
253 x 17
10.9 x 0.67
4.1 - 5.5
278 x17
3m
Ø 6 mm Min.
Ø 5 mm Min.
FIG 01
FIG 02
FIG 03
Air Consumption
Weight
Air Inlet
at load
5
6
[lb]
[l/min]
[inch]
[kg]
[SCFM]
0.9
240
1/8 BSP
0.4
8.5
1.8
390
1/8 BSP
0.8
13.8
1.3
390
1/8 BSP
0.6
13.8
1.5
390
1/8 BSP
0.7
13.8
2
390
1/8 BSP
0.9
13.8
2
13.8
1/4 BSP
0.9
6.5
P Max.
= 6.3 bar
B
Sound pressure
Inner Hose
Dia.
L
pA
7
8
[inch]
[dB(A)]
[mm]
3/8"
73
9.5
3/8"
76
9.5
3/8"
81
9.5
3/8"
76
9.5
3/8"
76
9.5
3/8"
73
9.5
Ø 12.5 mm
Push-to-start
Start
A
B
Vibrations
Soundpower
L
a
K
wA
hd
9
10
11
[dB(A)]
[m/s²] [m/s²]
84
>2.5
-
87
>2.5
-
92
>2.5
87
>2.5
-
87
>2.5
-
84
>2.5
-
