Technical data, abseiling rescue equipment, type ABS 3aW / ABS 3aWH
Values according to EN EN 341:2011/1A
max. 7,500,000 Joules
Minimum rated load 50 kg .............................15.200 abseil metres or with
Maximum rated load 140 kg .......................... 5.600 abseil metres
Values according to EN EN 341:2011/1B
max. 1,500,000 Joules
Minimum rated load 50 kg .............................15.200 abseil metres or with
Maximum rated load 200 kg ..........................
Values according to ANSI/ASSE Z359.4-2013
max. 7,500,000 Joules
Minimum rated load 59 kg .............................12.960 abseil metres or with
Maximum rated load 140 kg .......................... 5.600 abseil metres
the formula for calculating the abseil workload (W) lautet: W (joule) = m x g x h x n
W (Joule) = mass x g (9,81 m/s²) x abseil height x abseil sequences
Terms:
W = abseil workload (Joule), m = mass (kg), g (gravitational acceleration) = 9,81m/s²,
h = abseil height (m), n = number of abseil sequences
Caution: When reaching the maximum permissible abseil workload the device with the corresponding note in the
test log is always to send to the manufacturer!
Technical data, abseiling rescue equipment, type ABS 3a W
Standard: .............................................................. EN 341:2011/1A, EN 341:2011/1B, ANSI/ASSE Z359.4-2013
Weight without rope : ............................................. 1.7 kg
Maximum abseiling height: .................................... 200 m
Maximum load: ...................................................... 1 person / 140 kg (28 abseiling operations from a height of 200 m)
............................................................................... 2 person / 200 kg (4 abseiling operations from a height of 200 m)
Minimum load: ...................................................... 1 person / 50 kg (abseiling operations from a height of 200 m)
Test load EN: ........................................................ 250 kg (2 abseiling operations from a height of 200 m)
Static test load: ..................................................... 20 kN
Maximum load carrying capacity ANSI: ................. 140 kg
Abseiling speed ..................................................... 1.5 m/s
Technical data, abseiling rescue lifting equipment, type ABS 3a WH
Standard: ............................................................... EN 341:2011/1A; EN 341:2011/1B , EN 1496:2017 (A); ANSI/ASSE Z 359.4-2013
Weight without rope : ............................................. 2.5 kg
Maximum abseiling height: .................................... 200 m
Maximum load: ...................................................... 1 person / 140 kg (28 abseiling operations from a height of 200 m)
............................................................................... 2 person / 200 kg (4 abseiling operations from a height of 200 m)
Minimum load: ....................................................... 1 person / 50 kg (77 abseiling operations from a height of 200 m)
Maximum lifting capacity: ...................................... 200 m
crank force at max. rated load: .............................. 133 N
Test load EN: ......................................................... 250 kg
Static test load EN: ................................................ 20 kN
Maximum load carrying capacity ANSI: ................. 140 kg
Abseiling speed: .................................................... 1,5 m/s
ENGLISH
for reaching total permissible abseil workload (W)
for reaching total permissible abseil workload (W)
800 abseil metres
for reaching total permissible abseil workload (W)
22
28 x
200 m
4 x
200 m
