Quick Reference Guide

1. The electrical
regarding your electric fireplace
can be found on the rating label
located on the top of the unit.
2. If you have any technical
questions
Technical Information
Model No: XLF50-EU, XLF74-EU, XLF100-EU
Heat Output
Nominal Heat Output
Minimum Heat Output
Maximum Continous Heat Output P
Auxiliary Electricity Consumption
In Standby mode
with electronic room temperature control
Figure 1
6
All manuals and user guides at all-guides.com
information
or concerns
230V
P 1.6 - 1.6 kW
Nom
P -
min
1.6 - 1.6 kW
max,c
el 0.47 - 0.49 W
SB
XLF50 50.31 in [1278 mm]
XLF74 74.31 in [1887 mm]
XLF100 100.31 in [2548 mm]
XLF50 51.41 in [1306 mm]
XLF74 75.41 in [1941 mm]
XLF100 101.41 in [2576 mm]
regarding the operation of your
electric fireplace, or require
service contact the relavent
customer service as listed on
your warrenty card.
3. For dimensions
fireplace, refer to Figure 1.
240V
- - kW
of your
4.34 in.
110 mm
5.79 in.
147 mm
