There is a possibility to attach the safety support rack to the control unit. The safety
support rack can be attached to the left or the right side of the control unit and locked
by sliding it back.
Do not immediately run the heating element along iron or expose it to an alternating
electrical field. This can influence the regulation system.
When soldering and desoldering, take into consideration the soldering instructions of
the components, particularly their temperature limits.

5. Safety Notices

The manufacturer assumes no liability for uses other than those specified in the Opera-
tion Manual as well as any self-made changes to the unit.
This Operation Manual and the warning notices therein should be read carefully as well
as kept in good view and near the soldering unit. Failure to observe these warning
notices can lead to accidents, injuries or damage to health.
The WELLER Soldering Station WTCP-S complies with the EU Declaration of Conformity
according to the fundamental safety standards of the directive 89/336/EWG, 73/23/
EWG and 89/392/EWG.

6. Accessories List

53215299 FE50M Magnastat soldering iron with device for solder vapour suction
with picture
53209999 Extension cord 4m
52509999 A120K potential equalisation adapter
52609699 Press button adapter for potential equalisation
54173499 DIL-16-WG desoldering tip dual in line 16
54173899 DIL-24-WG desoldering tip dual in line 24 RM 7.62
54173999 DIL-24 desoldering tip dual in line 24 RM 15.24
54174599 DS-TO desoldering tip for round ICs TO-5
54173299 FP-7 Flat Pack soldering tip 9mm wide
51304099 Desoldering set DS-7
51302099 Tin-a-Print for tinning strip conductors
WTCPS.pm65 22

7. Extent of Delivery

Power unit PU-S / Soldering iron TCP-S / Safety support rack KH-20 / Operation Manual
Picture: Circuit diagram, see page 59+60
Picture: Exploded view, see page 61
Picture: ESD work place, see page 57
8. WARNING NOTICES!
1. Keep your work area in proper order.
Always return the soldering tool to its original holder when not in use. Do not bring
combustible materials near the hot soldering tools.
2. Take care for the surroundings.
Don't use the soldering tool in a moist or wet environment.
3. Protect yourself against electrical shocks.
Avoid touching grounded parts with your body, e.g. pipes, heating radiators, stoves, refrigerators.
4. Keep children at a distance.
Don't allow other persons to touch or disturb the soldering tool or cord. Keep other
persons away from your work area.
5. Store your soldering tool in an appropriate place
Unused soldering tools should be stored in a dry location which is out of the reach of
children (some place high or in a locked cabinet). Switch off all unused soldering tools.
6. Do not overload your soldering tool.
Use the soldering tool only with the specified voltage or specified pressure and pressure range.
7. Use the appropriate soldering tool.
Don't use a soldering tool whose performance is not adequate for your work. Never
use the soldering tool for purposes for which is was not designed.
8. Wear suitable work cloths.
There is a danger of burning yourself with liquid solder. Wear the corresponding
