MS-7788
Fan Power Connectors: CPuFAN, SySFAN, SySFAN2
the fan power connectors support system cooling fan with +2V. When connect-
ing the wire to the connectors, always note that the red wire is the positive and
should be connected to the +2V; the black wire is Ground and should be con-
nected to GNd. if the mainboard has a System Hardware Monitor chipset on-
board, you must use a specially designed fan with speed sensor to take advantage
of the CPu fan control.
CPuFAN/ SySFAN2 SySFAN
Parallel Port Connector: JLPt (optional)
this connector is used to connect an optional parallel port bracket. the parallel
port is a standard printer port that supports enhanced Parallel Port (ePP) and
extended Capabilities Parallel Port (eCP) mode.
