Locking & Limiting
Receiver Wiring (RF only)
RX1
ELECTRONICS
N L 1 2 3 4
COM
Note: 1) For mains voltage operated systems, link terminal 2 to mains live supply
2) Power supply to unit must not be switched by timeswitch
RX2 and RX3
ELECTRONICS
A
ZONE
ZONE
1 ON 1 OFF
B C 1 2 3 4 5 6
N L
COM ZONE
1 ON
TERMINAL 6
RX3 ONLY
ZONE ZONE ZONE
1 OFF 2 ON 3 ON
