FERMOD 6200 Notice D'instructions page 5

6 - The installer is required to ensure the traceability of assembly and inspection operations effectively carried out (EN 13241-
1 §6.4).
7 - The staff of the company installing the equipment, and / or staff of the user company in charge of specific functions, such as
maintenance, must be qualified, trained and certified in the case of particularly risky work, such as work under power (D.
Safety at work 89/655/EEC modified 95/63/EEC art.7 / CT art. R 233-2).
8 - The final user must carry out the periodical yearly or twice-yearly checks, or have them carried out, with keeping of a
maintenance register (D. Safety at work - 89/655/EEC modified 95/63/EEC - art. 4b / CT R 233-1-2 and R 233-11-1).
2 – CHARACTERISTICS
« Lever Handles / Internal and External 6200 »
These Handles are designed to fit horizontal sliding doors with specific characteristics (isothermal, acoustical, clean-rooms,
dust-tight)
When the door is closed, manual system equiped with tighteness gasket pushes the leaf to the frame and down to the floor.
The customer uses one of the handles to open the door and follows the door until the opening required. The retractable flat
pushes on the external butt so the door moves away from the floor and the frame
These handles are suitable to doors of dimensions and weights as per table here-below, whatever door or frame materials are
used.
Handles ref RH or LH
Internal/External handle ep. 080
Internal/External handle ep. 100
Internal/External handle ep. 120
Internal/External handle ep. 140
Internal/External handle ep. 160
An industrial or commercial door designed to be operated manually must be opened or closed with an effort below 260 N. This
value excludes the influence of wind or other environmental factors that are not to be taken into consideration. Higher values
can be allowed at the beginning of the opening or at the closing time.
EN 12604:2000 -4.4.1.
In case of motor failure, the door must be opened manually. The required physical effort to open the door may not exceed by
more than 50% the values indicated in the EN 12604 standard. EN 12453:2000 -5.3.5.
This product is in accordance with the above mentionned standards. The maximum effort for the external or internal handle is
390 Nm.
The operating temperature is between 0°C and + 55°C.
3 - TRANSPORT
The handle is packed :
- either within the manual system packing
- or with other compents in a box.
The original packing is designed for all types of transportation means. This equipment must be protected from bad weather
during transport.
The liability of FERMOD ceases :
- as soon as the customer of intaller opens the package or part of it
- as soon as the package has suffered a considerable impact in such a way that it's damaged.
4 - STORAGE
This equipment must be protected from the bad weather during storage.
The maxi door weight correspond to the manual system
- 5 -
Door thickness
mini maxi
60 80
81 100
101 120
121 140
141 160
Door weight
maxi
200 kg
200 kg
200 kg
200 kg
200 kg
NMPOIG6200/L
