Données De Construction Et D'entretien - Xylem LOWARA e-IXP Instructions D'installation, D'utilisation Et D'entretien

fr - Traduction de la notice originale
8.7 Données de construction et d'entretien
Modèle Diamètre des orifices,
mm (in)
Aspiration Refoulement
40-25-160, 40-25-200 40 (1 1/2)
40-25-250 40 (1 1/2)
50-32-160, 50-32-200 50 (2)
50-32-250 50 (2)
65-50-160 65 (2 1/2)
65-40-200 65 (2 1/2)
65-40-250, 65-40-315 65 (2 1/2)
80-65-125, 80-65-160 80 (3)
80-50-250, 80-50-315 80 (3)
100-80-125 100 (4)
100-80-160 100 (4)
100-65-200, 100-65-250 100 (4)
100-65-315 100 (4)
125-80-160, 125-80-200 125 (5)
125-80-250 125 (5)
125-80-315, 125-80-400 125 (5)
125-100-160 125 (5)
125-100-200 125 (5)
125-100-250 125 (5)
125-100-315 125 (5)
125-100-400 125 (5)
150-125-200 150 (6)
150-125-250 150 (6)
150-125-315 150 (6)
150-125-400 150 (6)
200-150-200 200 (8)
200-150-250 200 (8)
200-150-315 200 (8)
200-150-400 200 (8)
200-150-500 200 (8)
250-200-250 250(10)
250-200-315 250(10)
250-200-400 250(10)
250-200-500 250(10)
250-200-600 250(10)
300-250-315 300(12)
300-250-400 300(12)
300-250-500 300(12)
300-250-600 300(12)
350-300-350 350(14)
350-300-400 350(14)
350-300-450 350(14)
350-300-500 350(14)
400-400-400 400(16)
400-350-450 400(16)
500-500-500 500(20)
600-600-600 600(24)
44
Diamètre Garniture
de l'arbre, mécanique, mm
mm (po) (in)
25 (1) 24 (0.94) 33 (1.30)
25 (1) 32 (1.26) 43 (1.69)
32 (1 1/4) 24 (0.94) 33 (1.30)
32 (1 1/4) 32 (1.26) 43 (1.69)
50 (2) 24 (0.94) 33 (1.30)
40 (1 1/2) 24 (0.94) 33 (1.30)
40 (1 1/2) 32 (1.26) 43 (1.69)
65 (2 1/2) 24 (0.94) 33 (1.30)
50 (2) 32 (1.26) 43 (1.69)
80 (3) 24 (0.94) 33 (1.30)
80 (3) 32 (1.26) 43 (1.69)
65 (2 1/2) 32 (1.26) 43 (1.69)
65 (2 1/2) 42 (1.65) 53 (2.09)
80 (3) 32 (1.26) 43 (1.69)
80 (3) 32 (1.26) 43 (1.69)
80 (3) 42 (1.65) 53 (2.09)
100 (4) 32 (1.26) 43 (1.69)
100 (4) 32 (1.26) 43 (1.69)
100 (4) 42 (1.65) 53 (2.09)
100 (4) 42 (1.65) 53 (2.09)
125 (5) 42 (1.65) 53 (2.09)
125 (5) 42 (1.65) 53 (2.09)
125 (5) 42 (1.65) 53 (2.09)
125 (5) 42 (1.65) 53 (2.09)
125 (5) 42 (1.65) 53 (2.09)
150 (6) 42 (1.65) 53 (2.09)
150 (6) 42 (1.65) 53 (2.09)
150 (6) 48 (1.89) 65 (2.56)
150 (6) 48 (1.89) 65 (2.56)
150 (6) 60 (2.36) 80 (3.15)
200 (8) 48 (1.89) 65 (2.56)
200 (8) 48 (1.89) 65 (2.56)
200 (8) 60 (2.36) 80 (3.15)
200 (8) 60 (2.36) 80 (3.15)
200 (8) 80 (3.15) 100 (3.94)
250(10) 48 (1.89) 65 (2.56)
250(10) 60 (2.36) 80 (3.15)
250(10) 60 (2.36) 80 (3.15)
250(10) 80 (3.15) 100 (3.94)
300(12) 60 (2.36) 80 (3.15)
300(12) 60 (2.36) 80 (3.15)
300(12) 80 (3.15) 100 (3.94)
300(12) 80 (3.15) 100 (3.94)
400(16) 60 (2.36) 80 (3.15)
350(14) 80 (3.15) 100 (3.94)
500(20) 80 (3.15) 100 (3.94)
600(24) 80 (3.15) 110 (4.33)
e-IXP, e-IXPC, e-IXPF – Instructions d'Installation, d'Utilisation et d'Entretien
Type de palier
Côté pompe Côté moteur
6307-C3 3307-A-C3
6309-C3 3309-A-C3
6307-C3 3307-A-C3
6309-C3 3309-A-C3
6307-C3 3307-A-C3
6307-C3 3307-A-C3
6309-C3 3309-A-C3
6307-C3 3307-A-C3
6309-C3 3309-A-C3
6307-C3 3307-A-C3
6309-C3 3309-A-C3
6309-C3 3309-A-C3
6311-C3 3311-A-C3
6309-C3 3309-A-C3
6309-C3 3309-A-C3
6311-C3 3311-A-C3
6309-C3 3309-A-C3
6309-C3 3309-A-C3
6311-C3 3311-A-C3
6311-C3 3311-A-C3
6311-C3 3311-A-C3
6311-C3 3311-A-C3
6311-C3 3311-A-C3
6311-C3 3311-A-C3
6311-C3 3311-A-C3
6311-C3 3311-A-C3
6311-C3 3311-A-C3
6313-C3 3313-A-C3
6313-C3 3313-A-C3
NU314-ECP 7314-A-C3
6313-C3 3313-A-C3
6313-C3 3313-A-C3
NU314-ECP 7314-A-C3
NU314-ECP 7314-A-C3
NU320-ECP 7320-A-C3
6313-C3 3313-A-C3
NU314-ECP 7314-A-C3
NU314-ECP 7314-A-C3
NU320-ECP 7320-A-C3
NU314-ECP 7314-A-C3
NU314-ECP 7314-A-C3
NU320-ECP 7320-A-C3
NU320-ECP 7320-A-C3
NU314-ECP 7314-A-C3
NU320-ECP 7320-A-C3
NU320-ECP 7320-A-C3
NU320-ECP 7320-A-C3
Quantité de graisse, côté Quantité
pompe/côté moteur, g d'huile, L
(oz) (US qt à sec)
5/15 (0.18/0.53) 0.3 (0.3)
10/20 (0.35/0.71) 0.7 (0.7)
5/15 (0.18/0.53) 0.3 (0.3)
10/20 (0.35/0.71) 0.7 (0.7)
5/15 (0.18/0.53) 0.3 (0.3)
5/15 (0.18/0.53) 0.3 (0.3)
10/20 (0.35/0.71) 0.7 (0.7)
5/15 (0.18/0.53) 0.3 (0.3)
10/20 (0.35/0.71) 0.7 (0.7)
5/15 (0.18/0.53) 0.3 (0.3)
10/20 (0.35/0.71) 0.7 (0.7)
10/20 (0.35/0.71) 0.7 (0.7)
15/30 (0.53/1.06) 0.9 (1.0)
10/20 (0.35/0.71) 0.7 (0.7)
10/20 (0.35/0.71) 0.7 (0.7)
15/30 (0.53/1.06) 0.9 (1.0)
10/20 (0.35/0.71) 0.7 (0.7)
10/20 (0.35/0.71) 0.7 (0.7)
15/30 (0.53/1.06) 0.9 (1.0)
15/30 (0.53/1.06) 0.9 (1.0)
15/30 (0.53/1.06) 0.9 (1.0)
15/30 (0.53/1.06) 0.9 (1.0)
15/30 (0.53/1.06) 0.9 (1.0)
15/30 (0.53/1.06) 0.9 (1.0)
15/30 (0.53/1.06) 0.9 (1.0)
15/30 (0.53/1.06) 0.9 (1.0)
15/30 (0.53/1.06) 0.9 (1.0)
20/40 (0.71/1.41) 1.8 (1.9)
20/40 (0.71/1.41) 1.8 (1.9)
30/50 (1.05/2.12) 2.6 (2.8)
20/40 (0.71/1.41) 1.8 (1.9)
20/40 (0.71/1.41) 1.8 (1.9)
30/50 (1.05/2.12) 2.6 (2.8)
30/50 (1.05/2.12) 2.6 (2.8)
40/80 (3.6/3.8) 6 (6.3)
20/40 (0.71/1.41) 1.8 (1.9)
30/50 (1.05/2.12) 2.6 (2.8)
30/50 (1.05/2.12) 2.6 (2.8)
40/80 (3.6/3.8) 6 (6.3)
30/50 (1.05/2.12) 2.6 (2.8)
30/50 (1.05/2.12) 2.6 (2.8)
40/80 (3.6/3.8) 6 (6.3)
40/80 (3.6/3.8) 6 (6.3)
30/50 (1.05/2.12) 2.6 (2.8)
40/80 (3.6/3.8) 6 (6.3)
40/80 (3.6/3.8) 6 (6.3)
40/80 (3.6/3.8) 6 (6.3)
