Caution: A few wireless expanders installed close to each
other may interfere. In this case, use a different frequency
hopping pattern by setting appropriate DIP switches.
Table 1: Address DIP switch settings
DIP switches 1/2/3/4* Advisor Advanced
bus address
0000 Not allowed
1000 1
0100 2
1100 3
0010 4
1010 1
0110 2
1110 3
0001 4
1001 1
0101 2
1101 3
0011 4
1011 1
0111 2
1111 3
0 — Off, 1 — On
*
Address 1 configuration is shown in Figure 3.
Powering up ATS1238
1. Before powering up the panel and receiver module, verify
that all wiring at the panel and ATS1238 wireless receiver
is correct.
2. Connect the panel backup battery and AC power.
Configuring wireless sensors, zones, and
PIR cameras
Refer to Advisor Advanced Installation and Programming
Manual for details.
Connection quality
See Advisor Advanced Installation and Programming Manual
for more information.
Verifying the connection quality via control panel menu
You can verify the connection quality using appropriate control
panel internal menus.
The approximate connection quality levels are listed in Table 2
below.
Table 2: RSSI values
Value Screen bar Received signal
(dBm) indicator
Weak signal. The senor may work, but the
<−90 [.I.........]
operation is not recommended, because the
wireless device will cause RF supervisory
faults.
P/N 1079519 (ML) • REV G • ISS 19OCT20
Value
(dBm)
−90 to −75 [.I.I.......]
−74 to −53
Frequency
−52 to −37
hopping pattern
>−37
Not allowed
HDR receiver communication quality is measured in
1
percentage, from 0% (no signal) to 100% (best signal).
2
3
Verifying the connection quality via camera range test
4
Range test allows you to verify wireless PIR camera signal
5
reception. In this mode, selected wireless PIR cameras show
the reception quality with alarm LED colour:
6
•
7
•
8
•
9
10
The LED follows the weakest communication link of LDR and
HDR.
11
12
Privacy note
13
14
Prior to dismantling the system, or replacing ATS1238 wireless
15
expander or one of wireless PIR cameras, ensure that all
stored pictures have been deleted. It takes approximately 3
minutes to delete all pictures.
Supported wireless devices
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Screen bar Received signal
indicator
Good signal. The sensor works, although
supervision for this RF device may have to
be switched off.
[.I.I.I.....] Strong signal
[.I.I.I.I...]
[.I.I.I.I.I.]
Green: Strong signal, RSSI>−75 dBm and QI>70%
Orange: Good signal, RSSI is −90 to −75 dBm, or QI is 51
to 70%
Red: Weak signal, RSSI is <−90 dBm, or QI is <51%
TX-2344-03-1 Wireless mirror PIR camera 868 MHz, white
TX-1011-03-1 Wireless Slimline door/window contact,
868 MHz GEN2, white
TX-1011-03-3 Wireless Slimline door/window contact,
868 MHz GEN2, brown
TX-1211-03-1 Universal Transmitter, 868 MHz GEN2,
white
TX-1211-03-3 Universal Transmitter, 868 MHz GEN2,
brown
TX-2211-03-1 Wireless PIR motion sensor, 868 MHz
GEN2
TX-2212-03-1 Mirror PIR, 868 MHz GEN2, Pet Immune
TX-2411-03-1 Wireless PIR/MW motion sensor, 868 MHz
GEN2
TX-6211-03-1 Wireless optical smoke/heat sensor,
868 MHz GEN2
TX-6212-03-1 Wireless optical smoke/heat sensor,
868 MHz GEN2
TX-4131-03-2 Wireless 4-button keyfob, 868 MHz GEN2
TX-3011-03-1 868 GEN2 2-button pendant panic, white
TX-5011-03-1 Shock sensor, 868 MHz GEN2, white
TX-5011-03-3 Shock sensor, 868 MHz GEN2, brown
