Recommended separation distances between portable and
mobile RF communications equipment and the EQUIPMENT or
SYSTEM
Recommended separation distances between
portable and mobile RF communications equipment and the model Grid Pad 15
The Model Grid Pad 15 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled.
The customer or the user of the Model Grid Pad 15 can help prevent electromagnetic interference by maintaining a minimum
distance between portable and mobile RF communications equipment (transmitters) and the Model Grid Pad 15 as recommend-
ed below, according to the maximum output power of the communications equipment.
Rated maximum output of
transmitter
W
0.01
0.1
1
10
100
For transmitters rated at a maximum output power not listed above the recommended separation distance d in metres (m) can
be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of
the transmitter in watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection
from structures, objects and people.
124
Separation distance according to frequency of transmitter m
150 kHz to 80 MHz
0.12
0.37
1.17
3.7
11.7
80 MHz to 800 MHz
0.04
0.12
0.35
1.11
3.5
800 MHz to 2.7 GHz
0.07
0.23
0.7
2.22
7.0
